DeWALT® Power-Stud+® SD1 7416SD1 Expansion Wedge Anchor, 3/8 in dia, 5 in OAL, 3-5/8 in L Thread, Carbon Steel, Zinc Plated
SKU
ANC28175
UPC #075352775852
Manufacturer #7416SD1-PWR
$0.67
$0.67
Quantity Break Pricing may apply in the cart
Availability:
Call for availability
Description
Powers™ Power-Stud+® SD1 wedge anchor, Expansion, 3/8 in dia, 5 in Overall Length, 3-5/8 in Thread Length, Carbon Steel, Zinc Plated, 1-5/8 in Minimum Embedment Depth, 3/8 in Drill, 3/8-16, Hex Head, UNC, 2540 lb Shear Strength, 2685 lb Tensile.
Features
- Consistent performance in high and low strength concrete
- Nominal drill bit size is the same as the anchor diameter
- Anchor can be installed through standard fixture holes
- Anchor design allows for follow-up expansion after setting under tensile loading
- Length ID code and identifying marking stamped on head of each anchor
- Anchor design allows for follow-up expansion after setting under tensile loading ultimate pullout 5440 lb
- Normal weight concrete, structural sand-light weight concrete, concrete over steel deck and grouted concrete masonry are applicable materials
Specs
| Manufacturer Part Number | 7416SD1-PWR |
|---|---|
| Manufacturer | Stanley Black & Decker |
| Brands | DEWALT |
| UPC | 075352775852 |
| Length (in) | 5 |
| Height (in) | 0.375 |
| Standard Approvals |
|
| Type | Expansion |
| Head Style | Hex |
| Thread Size | 3/8 in - 16 |
| Thread Type | UNC |
| Diameter | 3/8 in |
| Material | Carbon Steel |
| Thread Length | 3-5/8 in |
| Package Quantity | 1/Each |
