Crosby® 1018856 G-215 Chain Shackle, 1 ton Working Load Limit, 3/8 in Nominal Size, 7/16 in Round Alloy Pin, Hot-Dipped Galvanized

SKU
FIT10988
Manufacturer #1018856
$9.81
$18.80
Quantity Break Pricing may apply in the cart
Availability:
Generally in stock, call for availability
Crosby® Chain Shackle, Series: G-215, 1 ton, 3/8 in, 7/16 in Pin dia, Round Pin, 1.28 in Inner Length, 0.66 in Inner Width, 0.66 in Opening, 0.92 in Eye Outer Size, 2-5/16 in OAL, 1.86 in Overall Width, Carbon Steel Body, Alloy Pin, Hot Dipped Galvanized
Features
  • Working load limit permanently shown on every shackle
  • Shackles are quenched and tempered and can meet DNV impact requirements of 42 J at -20 deg C
  • Look for the Red Pin® the mark of genuine Crosby® quality
More Information
Manufacturer Part Number 1018856
Manufacturer Crosby Group
Brand Name CROSBY®
Length (in) 2.3125
Width (in) 1.86
Standard Approvals
  • ABS/DNV/Lloyds/CE Certified
  • Federal Spec RR-C-271F
  • Type IVA
  • Grade A
  • Class 1
Series G-215
Shackle Size 3/8 in
Pin Diameter 7/16 in
Eye Outer Size (in) 0.92
Opening Size 0.66 in
Inner Width 0.66 in
Inner Length 1.28 in
Body Material Carbon Steel
Pin Material Alloy
Pin Type Round
Finish Hot Dipped Galvanized
Write Your Own Review
You're reviewing:Crosby® 1018856 G-215 Chain Shackle, 1 ton Working Load Limit, 3/8 in Nominal Size, 7/16 in Round Alloy Pin, Hot-Dipped Galvanized
Datasheet (418.78 kB)
