CM® Lodestar® 9502 Triple Reeving Electric Chain Hoist, 3 ton Load, 11 ft Chain/Rope, 15 ft H Lifting, 1 hp Power Rating, 115 VAC

SKU

9502-10449

UPC #043927695027

Manufacturer #9502

Be the first to review this product

$5,625.51

Quantity Break Pricing may apply in the cart

Availability:

Call for availability

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Description

CM® Classic Lodestar® Electric Chain Hoist, Triple Reeving, 3 ton, 11 ft, 15 ft Lifting Height, 5.5 FPM Lift Speed, 29-9/16 in Minimum Between Hooks, 1-Speed/NEMA 4X Pushbutton Control Pendant Control, 1 hp, 115 VAC, 14.2 A, Blue, 20-3/16 in L x 12-11/16 in W x 7-13/16 in D. The CM® Lodestar® Electric chain hoist is recognized as the standard in the overhead lifting industry. Generations of users have relied on the power and dependability of the Lodestar® for over 50 years. Available as individual Units, in hoist/trolley combinations or as integral components of complete lifting systems, the Lodestar® takes lifting to new Heights for professionals in any industry.

Features

Quick-change voltage board change from low voltage to high voltage by simply repositioning receptacle
Gear train lifetime lubricated with non-oxidizing grease
Precision machined and hardened lift wheel with hardened chain guides for precise chain lift wheel fit
Gearing designed for exceptionally long life and quiet operation
Hoist duty motor, standard protector overload device and standard screw type limit switches
Hardened, forged steel, latch type hooks and Hoistaloy® load chain for long, dependable service
No special tools required to disassemble
Each hoist thoroughly inspected and tested to over 125 percent of rated load prior to shipment
H4 duty cycle
Easy to install and maintenance
Harsh environment hoists available for severe duty of plating, galvanizing and wash down applications
Hoists with climbing capability available for temporary rigging or lifting applications, must be used in inverted position only
Hoists with creep control allow precise positioning through field adjustment within the time delay range of 0.05 sec to 3 sec
Articulating suspension 3 ton only
For heavy duty industrial applications

Specs

More Information
Manufacturer Part Number	9502
Manufacturer	Columbus McKinnon Corporation
Brand Name	CM
UPC	043927695027
Length (in)	20.1875
Width (in)	12.6875
Height (in)	7-10.1875
Color	Blue
Standard Approvals	ASME B30.16
Type	Triple Reeving
Load Capacity	3 ton
Voltage	115V AC
Lifting Height	15 ft
Package Quantity	1/Each
